Topical Therapy for non-invasive penile cancer (Tis)—updated results and toxicity
Review Article

Topical Therapy for non-invasive penile cancer (Tis)—updated results and toxicity

Aditya Manjunath1, Thomas Brenton1, Sarah Wylie1, Catherine M. Corbishley2, Nick A. Watkin1

1Department of Urology, 2Department of Cellular Pathology, St George’s Hospital, London, UK

Contributions: (I) Conception and design: NA Watkin; (II) Administrative support: None; (III) Provision of study material or patients: A Manjunath; (IV) Collection and assembly of data: None; (V) Data analysis and interpretation: None; (VI) Manuscript writing: All authors; (VII) Final approval of manuscript: All authors.

Correspondence to: Mr. Aditya Manjunath. Department of Urology, St George’s Hospital, London, UK. Email: aditya.m@doctors.org.uk.

Abstract: Penile cancer is a rare malignancy estimated to affect 26,000 men globally each year. The association with penile cancer, in particular non-invasive disease, and human papilloma virus (HPV) is well known. Ninety-five percent of cases of penile cancer are squamous cell carcinoma (SCC), which are staged using the TNM staging system. Terminology describing the histological appearance of non-invasive penile cancer has changed with all cases grouped under the umbrella term of penile intraepithelial neoplasia (PeIN); either undifferentiated or differentiated. This replaces previous terms such as carcinoma in situ (CIS) and eponymous names such as Bowen’s disease. This change is recognised by the World Health Organisation (WHO). The topical treatments most commonly used for PeIN are 5-fluorouracil (5-FU) and imiquimod (IQ). Other treatments such as photodynamic therapy (PDT) are used but to a lesser degree. The evidence for all of these treatments is heterogenous with no randomised data available. Overall up to 57% complete response has been reported with a low number of serious adverse events. In this article, we aim to review the available evidence for the topical treatment of non-invasive penile cancer specifically regarding its efficacy and toxicity.

Keywords: Carcinoma in situ (CIS); penile intraepithelial neoplasia (PeIN); 5-flurouracil (5-FU); imiquimod (IQ)


Submitted Apr 18, 2017. Accepted for publication Jun 15, 2017.

doi: 10.21037/tau.2017.06.24


Epidemiology of penile cancer

Penile cancer is a rare malignancy. It has been estimated to affect 26,000 men globally every year. The incidence appears to be particularly higher in the developing countries; however regions with religious practices that exercise neonatal circumcision appear to experience lower incidence rates (1). Incidence rates of penile cancer in the UK was estimated at 0.1/100,000 (man-years), with approximately half of these cases attributed to human papilloma virus (HPV). The histology behind penile cancer is commonly squamous cell carcinoma (SCC) 95%, which is highly associated with HPV 16/18 (2).


What is Non-invasive penile cancer?

Penile cancer is staged via the current 7th edition AJCC TNM staging system (Table 1) (3). To improve the accuracy of staging, a complete resection of the site insuring negative surgical margins is preferable to a biopsy. Several factors are taken into account with staging, determining whether the cancer is invasive, or non-invasive. Once it has been classified, the appropriate treatment options can be explored. A non-invasive cancer constitutes as a carcinoma in situ (CIS), which has not invaded the sub-epithelial connective tissue and has not spread to the lymphovascular system (4).

Table 1
Table 1 2009 TNM clinical and pathological classification of penile cancer (3)
Full table

Updated histopathological and clinical terminology

In recent years there has been a change of terminology used in the histopathological classification of premalignant penile lesions. In order to better understand the management of these lesions it is essential to be clear about these changes.

Previously a number of terms existed in the histopathological description of premalignant lesions. These include penile intraepithelial neoplasia (PeIN), squamous CIS, high grade squamous intraepithelial lesions (HSIL) and low grade squamous intraepithelial lesion (LSIL) (5). In addition PeIN has been further subdivided into grade I to III (low to high grade).

A simpler classification has been proposed and endorsed by the World Health Organisation (WHO) (6). This acknowledges the role of HPV in the pathophysiology of these lesions (7). The change in classification has resulted in removal of all of the above terms including the subgrouping of PeIN to leave two categories; undifferentiated PeIN or differentiated PeIN.

Undifferentiated PeIN encompasses the clinically defined entities of Bowen’s disease and erythroplasia of Queyrat, as well as previously defined squamous CIS (Figure 1). Since the recognition of the role of HPV, undifferentiated PeIN can be further subdivided into basaloid and/or warty subtypes (5). These are frequently associated with HPV 16. The association between undifferentiated PeIN and invasive warty and basaloid type tumours encourages treatment undifferentiated PeIN as opposed to observation (6).

Figure 1 Pathologic slide demonstrating undifferentiated PeIN (400× magnification). PeIN, penile intraepithelial neoplasia.

Differentiated PeIN is defined histologically by atypical squamous cells which are confined to the lower layers of the penile squamous epithelium. It is usually associated with architectural atypia, elongated rete ridges and aberrant intraepithelial keratinisation (Figure 2). It is not usually associated with high risk HPV subtypes (5).

Figure 2 Pathologic slide demonstrating differentiated PeIN (400× magnification). PeIN, penile intraepithelial neoplasia.

Diagnosis of non-invasive penile cancer

PeIN typically presents as a solitary lesion on the penis, and usually presents in men over the age of 35, with a peak incidence of 60–70 years. According to the British Association for Sexual Health and HIV (BASHH) guidelines any suspicious persistent or atypical penile lesions should be managed with a full anogenital examination followed with a biopsy to confirm the diagnosis and exclude invasive malignancy (8). When assessing the penis by clinical examination, we recommend using a swab soaked with 5% acetic acid on the genital skin. After a few minutes abnormal epithelium demonstrates an “aceto-white” reaction. Although not specific for premalignant changes, Wikström et al. identified 20% of men with aceto-positive reaction as having PeIN (9).


Aim of review

Currently European Association of Urology (EAU)© guidelines suggest non-invasive penile malignancy can be managed with topical treatments such as Imiquimod (IQ) or 5-FU. Although, other options have been suggested such as total or partial glans resurfacing which have shown up to 20% of patients had superficial invasive disease (3). The aim of this review will be to update readers on the topical treatment options specifically with regards to their efficacy and toxicity.


Topical treatment of non-invasive penile cancer

The two main topical treatments for non-invasive penile cancer are 5-fluorouracil (5-FU) and IQ. The next section provides the up to data evidence of their efficacy as well as their toxicity. The EAU© guidelines report that for CIS, up to 57% of patients reported a complete response with a low number of adverse events (3).

5-FU

5 Fluoro Uracil exerts its chemotherapeutic effects through inhibition of the enzyme thymidylate synthetase (10). The antimetabolite effects occur through increased uptake in rapidly dividing cancer cells. 5-FU was first recognised in the 1960s as a treatment for Actinic Keratosis. As this became a widely practiced way of topical and effective management it was trialed in other topical low grade cancers, in particular penile cancer (11). Penile tissue is suited to topical 5-FU treatment as recurrence from secondary progression of bowenoid areas from hair follicles is common (12). This is a significant step as tissue preservation in penile cancer is very important for psychological and sexual preserving reasons. 5-FU is a topical agent and it is well tolerated by patients. Close follow up is of particular importance in topical therapies for cancers. If the initial course of topical 5-FU fails, then this treatment is not usually repeated (3).

One of the first studies assessing 5-FU in less aggressive superficial penile cancer showed in the group of patients treated with 5FU the post treatment biopsies were normal, with a 70-month follow up (13). Even though this study had a small treatment group (n=7), there was a significant treatment effect. These findings were also replicated in a small study (n=3), patients were recurrence free from a follow up time of between 20–60 months (14). These findings have been shown in further studies on larger scales. In a retrospective study of 86 patients with penile CIS, followed over a 10-year period showed that topical 5-FU had a 50% complete response compared to 44% in IQ. Thirty-one percent of patients treated with 5-FU had a partial response, while IQ had 56% non-response (15). These are the two main stay topical therapies in superficial penile cancers. Although the numbers in the study are small, there is a notable difference between 5-FU and IQ. It is challenging to come to a firm conclusion as there is limited evidence available and moreover existing data has small numbers and are not randomised controlled trials. As there is a limited evidence base in topical treatment for superficial less aggressive penile cancer it is beneficial to see that topical therapies have a substantial effect. Moreover with close surveillance of the patients detrimental effects of the disease progression can be curtailed.

IQ

IQ is an immuno-modulating drug which acts on several levels of the adaptive immune system. It activates the cells of this aspect of the immune system through toll like receptor 7 (TLR-7) causing secretion of cytokines such as interferon alpha, interleukin 6 (IL-6) and tumour necrosis factor alpha. The treatment is usually given for 5 days a week for a period of 4 to 6 weeks. The evidence for the use of topical IQ in PeIN is very heterogenous with most data coming from small case series and case reports. There has been more extensive use of IQ in extra genital CIS. A recent review picked up a total of 29 articles (22 case reports and 7 small case series) where IQ was used in the treatment of PeIN. In total this amounts to 48 patients, this is the largest aggregated number of patients in a review of IQ treatment to date. The majority of patients present with the clinical entity erythroplasia of query at (n=32), the remaining present with Bowen’s disease (n=8) or bowenoid papulosis (n=8). The small studies included in this review are quite heterogenous; the duration of treatment, frequency of application etc. is very variable. This makes drawing firm conclusions about the efficacy of topical IQ difficult. From the data we have, 30 out of 48 patients demonstrated a complete response (62.5%), 4 patients (8%) had a partial response and 14 patients (29%) no response. Treatment given less than 4 times weekly appears to give a longer duration of complete response (81% complete response), although, inevitably the treatment regime lasts longer (mean duration 113 days). This compares with a 68% complete response in those patients receiving treatment greater than 4 times weekly (mean duration 53 days) (16).

Toxicity data for the use of topical IQ is reported in extra genital disease. The most common adverse effect is local skin irritation at the application site. Other adverse effects include headache, flu like symptoms and myalgia. In our experience of a small number of patients treated with topical IQ for PeIN it is well tolerated. There is no evidence to suggest that any patients have ceased treatment due to toxicity.


Other treatment modalities for non-invasive penile cancer

In our tertiary referral center those patients who relapse following topical chemotherapy for the treatment of their non invasive penile cancer are offered surgery. This is either in the form of partial or total glans resurfacing, this has been shown to identify 20% of patients with underlying invasion. Other treatments such as photodynamic therapy (PDT), laser ablation and Mohs micrographic surgery are also used. The disadvantage of PDT and laser ablation are the lack of histological tissue for analysis. Evidence for these treatments once again is rather heterogeneous with small study populations. Filonenko et al. treated 10 patients over a 2-year period with PDT and achieved complete response in 9 patients (17). The follow up period was short and this illustrates the difficulties in demonstrating durability of this treatment. PDT was used to treat 7 out of 10 patients successfully with a mean follow up of 35 months by Paoli’s group in Sweden. Three patients recurred with PeIN but no patient developed invasive cancer (18). Reported toxicity was minor with all patients experiencing a degree of pain, although this was not quantified. In addition superficial erosions were common but reportedly healed in a matter of days (18). Comparative trials of the various treatments available for non invasive penile cancer have not been performed to date.


Conclusions

The management of this rare disease has only been assessed in relatively small trials and no randomized evidence exists to guide best practice. It is clear that in select cases topical chemotherapy can provide an excellent treatment response with minimal long term side effects. Future double blinded randomized trials comparing different these different topical treatment modalities for non invasive penile cancer are essential to provide a more definitive answer as to the anticipated long term outcomes with such therapeutic agents.


Acknowledgements

None.


Footnote

Conflicts of Interest: The authors have no conflicts of interest to declare.


References

  1. Christodoulidou M, Sahdev V, Houssein S, et al. Epidemiology of penile cancer. Curr Probl Cancer 2015;39:126-36. [Crossref] [PubMed]
  2. Hartwig S, Syrjänen S, Dominiak-Felden G, et al. Estimation of the epidemiological burden of human papillomavirus-related cancers and non-malignant diseases in men in Europe: a review. BMC Cancer 2012;12:30. [Crossref] [PubMed]
  3. Hakenberg OW, Watkin N, Compérat E, et al. EAU Guidelines on Penile Cancer 2016. Available online: https://uroweb.org/wp-content/uploads/EAU-Guidelines-Penile-Cancer-2016-Pocket.pdf
  4. Heyns CF, Mendoza-Valdés A, Pompeo AC. Diagnosis and staging of penile cancer. Urology 2010;76:S15-23. [Crossref] [PubMed]
  5. Kaul A, Corbishley CM, Watkin NA. Diagnosis and management of premalignant penile lesions. In: Culkin DJ. Editor. Management of Penile Cancer. New York: Springer Science + Business Media, 2014:107-122.
  6. Chaux A, Pfannl R, Lloveras B, et al. Distinctive association of p16INK4a overexpression with penile intraepithelial neoplasia depicting warty and/or basaloid features: a study of 141 cases evaluating a new nomenclature. Am J Surg Pathol 2010;34:385-92. [Crossref] [PubMed]
  7. Moch H, Cubilla AL, Humphrey PA, et al. The 2016 WHO Classification of Tumours of the Urinary System and Male Genital Organs-Part A: Renal, Penile, and Testicular Tumours. Eur Urol 2016;70:93-105. [Crossref] [PubMed]
  8. 2008 UK National Guideline on the Management of Balanoposthitis. Clinical Effectiveness Group. British Association for Sexual Health and HIV. Available online: https://www.bashh.org/documents/2062.pdf
  9. Wikström A, Hedblad MA, Johansson B, et al. The acetic acid test in evaluation of subclinical genital papillomavirus infection: a comparative study on penoscopy, histopathology, virology and scanning electron microscopy findings. Genitourin Med 1992;68:90-9. [PubMed]
  10. Eaglstein WH, Weinstein GD, Frost P. Fluorouracil: mechanism of action in human skin and actinic keratoses. I. Effect on DNA synthesis in vivo. Arch Dermatol 1970;101:132-9. [Crossref] [PubMed]
  11. Micali G, Lacarrubba F, Nasca MR, et al. Topical pharmacotherapy for skin cancer. J Am Academ Dermatol 2014;70:1-12. [Crossref]
  12. Schellhammer PF, Jordan GH, Robey EL, et al. Premalignant lesions and nonsquamous malignancy of the penis and carcinoma of the scrotum. Urol Clin North Am 1992;19:131-42. [PubMed]
  13. Goette DK, Carson TE. Erythroplasia of Queyrat: treatment with topical 5-fluorouracil. Cancer 1976;38:1498-502. [Crossref] [PubMed]
  14. Goette DK, Elgart M, DeVillez RL. Erythroplasia of Queyrat. Treatment with topically applied fluorouracil. JAMA 1975;232:934-7. [Crossref] [PubMed]
  15. Alnajjar HM, Lam W, Bolgeri M, et al. Treatment of Carcinoma in Situ of the Glans Penis with Topical Chemotherapy Agents. Eur Urol 2012;62:923-8. [Crossref] [PubMed]
  16. Deen K, Burdon-Jones D. Imiquimod in the treatment of penile intraepithelial neoplasia: An update. Australas J Dermatol 2017;58:86-92. [Crossref] [PubMed]
  17. Filonenko E, Kaprin A, Alekseev B, et al. Own experience in treatment of patients with penile cancer using photodynamic therapy. Biomed Res Int 2015;2015:245080. [Crossref] [PubMed]
  18. Paoli J, Ternesten Bratel A, Löwhagen GB, et al. Penile intraepithelial neoplasia: results of photodynamic therapy. Acta Derm Venereol 2006;86:418-21. [Crossref] [PubMed]
Cite this article as: Manjunath A, Brenton T, Wylie S, Corbishley CM, Watkin NA. Topical Therapy for non-invasive penile cancer (Tis)—updated results and toxicity. Transl Androl Urol 2017;6(5):803-808. doi: 10.21037/tau.2017.06.24
